For homeowners who don’t just want to mow their lawn but prefer to manicure it. After all, this is a residential mower often mistaken for a commercial unit. It has the power, durability, and high performance that lawn aficionados demand – causing them to ask whether or not their lawn is worthy of such a machine.
Power Train
| Model Number | 991277 |
| Engine | Kawasaki FR691V |
| Horsepower | 23 |
| Engine Displacement | 44.3 in / 726 cc |
| Fuel Capacity | 5.1 gal / 19.3 ltr |
| Drive System | Hydro-Gear ZT-3100 Transaxles |
| Transmission Type | Hydrostatic |
| Brake Type | Lever Activated Parking |
| Driver Position | Sit |
| Ground Speed Forward | 8 mph / 12.9 kph |
| Ground Speed Reverse | 4 mph / 6.4 kph |
| Wheels Front | 13.0 x 6.5 in – 6.0 in (33.0 x 16.5 cm – 33.0 cm) |
| Wheels Rear | 22.0 x 11.0 in – 10.0 in (55.9 x 27.9 cm – 25.4 cm) |
Electric
| Battery Capacity | 190 CCA |
| Number of Batteries | 1 |
| Battery Voltage | 12 |
| Battery Type | AGM |
| Battery Size | U1 Compatible |
Deck
| Deck Size | 52 in / 132.1 cm |
| Coverage Hour | 4.2 acres / 1.7 hectares |
| Spindle Type | Mechanical |
| Deck Material | 7 ga |
| Deck Construction | Fabricated X-Factor 3 |
| Discharge Configuration | Side |
| Cutting Height Min | 1.5 in / 3.8 cm |
| Cutting Height Max | 5 in / 12.7 cm |
| Cutting Width | 52 in / 132.1 cm |
Dimensions
| Weight (assembled) | 817 lb |
| Length | 79 in / 200.7 cm |
| Width (Chute Up) | 56.2 in / 142.7 cm |
| Width (Chute Down) | 67.3 in / 170.9 cm |
