The VH series is a suitable for tractors from 75 to 125 horsepower with category 2 or 3 hitch. The VH models are heavy-duty and dependable, cutting through very demanding and stony soils. The speed of the rotor can be adjusted.
Model Specs
VH-90
| Product Family | VH Series |
| Product | VH-90 |
| Description | 90" Extreme Duty Gear Drive Tiller |
| Rotation | Forward |
| RPM | 540 |
| HP Required | 75 – 125 |
| Working Width | 90" |
| Max Working Depth | 9" |
| # of Flanges on Rotor | 9 |
| # of Tines per Flange | 6 |
| Total # of Tines | 54 |
| Rotor Thickness or Diameter | 3-1/2" |
| Rotor Swing Diameter | 17" |
| Overall Width | 95" |
| Weight (lbs) | 1557 lbs |
| Hitch | Cat 2 or 3 |
