Excavator Cutter Mount Under 12K

CIDAttachments.com HYDRAULIC BREAKERS EXCAVATOR MODELS – SIDE MOUNT Applicable for the full range of excavators. Easy maintenance. Has lower installation point so breaker can lift higher. Primarily for post and pile driver applications and other specialized uses. Warning: Chisel paste must be used with hydraulic breakers, using high temperature grease as substitution for chisel paste will cause damage to components of breaker. Weights may differ based on selected mount styles. Prices and specifications subject to change without notice. Description Unit CBR225 CBR500 CBR650 CBR850 CBR1000 Energy Class ft lbs 225 500 650 850 1,000 Operating Weight Kg 122 190 280 350 510 lb 269 419 618 772 1,124 Hose Length In .5" x 90" .5" x 100" .5" x 100" .75" x 100" .75" x 100" Operating Pressure Kg/cm 90~120 90~120 110~165 120~165 140~170 Psi 1,280~1,707 1,280~1,707 1,565~2,347 1,707~2,347 1,991~2,418 Tool Diamater mm 45 57 70 75 80 Inch 1.77 2.24 2.75 2.95 3.14 nd Relief Setting Pressure Kg/cm Psi 2,489 2,500 2,500 2,500 2,500 Oil Flow LPM 15~30 20~70 30~65 38~80 38~90 GPM 3.96~7.92 5.2~10.5 7.9~17.1 10~21.1 10~23.7 Blow Rate Bpm Long/s 540~1,000 600~1,490 550~1,300 380~1,100 380~1,000 Bpm Short/s 490~1,100 Accumulator Gas Pressure Kg/cm – – 40~50 40~50 40~50 Psi – – 570 ~ 710 570~710 570~710 Suitable Carrier ton 0.8~2.5 1.5~4.0 3.0~6.0 4.5~8.0 4.5~8.8 Floating Power Cell and Bolt Free Enclosed Housing

tool, front head, piston, through bolt and diaphragm even with frequent dry-firing applications such as rental, secondary rock breaking and scaling

• Prevents carrier boom and arm fatigue failure
• No metal-to-metal contact
• Floating and fully enclosed power cell
• Extended breaker and carrier service life
• Low noise
• Suitable for all applications, particularly trenching, quarry and mining
• Built-in cylinder
• Energy efficiency
• Oil leakage free
• Thicker flesh cylinder block
• Lower maintenance and repair requirements
• Optimizes power and speed for application requirements
• Enables maximum productivity in all applications from light to
• Available for CBR1000 and above
• Proactivetly prevents carrier hydraulic part fatigue failure
• Accelerates striking performance
• Prevents cavitation
• Increases seal and diaphragm service life
• Available for CBR650 and above (excluding skid steer
• Minimizes direct contact between
• Protects tool pin hole damage from debris
• Extends tool pin and working tool wear life
• Prevents hole cover missing and debris/dust entry
• Faster response time to breaker activation signal
• Significantly increases productivity
• Suitable for skid steer loader breaker applications
• Available for CBR500, CBR650 and CBR850
• Anti-abrasive high-tensile raw material
• Fully-enclosed lower bushing and front
• Minimize debris and dust entering
• Increases service life of housing, tool,
• Heat-treated core surface
• Optimum balance for longer wear life and
• Variety of conventional and special
• Percussion chamber
• Prolongs lubrication
• Prevents contamination
• Increases life of seal, bushings,
• Heavy-duty oval shape
• Heat-treated and
• Longer-wear life
• Maintenance friendly design –
• Dual pin models available
• Differentiated anti-wear
• Higher core hardness
• Extended wear life
• Hybrid energy-efficient design
• Higher impact power delivery
• Lower oil flow consumption
• Durable piston design – larger surface
• Dampens repercussion vibration force
• Prevents carrier structure fatigue failure
• Gas charging from external housing
• No need for housing or lubrication
• Lower maintenance time
• Designed for easy maintenance at the
• Automatically cuts off hydraulic power
• Ensures service life of tool pin, working
• Standard for CBR2200 and above and
• Built in air supply channel
• Designed for underwater, tunneling
• Significantly enhanced front head
• Extended front head service life
• Hydraulic auto-lube system standard on
• Higher impact power
• Higher productivity
• Market-proven quality, durability
• Easy maintenance and repair
• Low-fatigue stress on carrier machines
• Reasonable cost
• Lower operating cost
• Higher return on investment

X-treme Auger Drive Specs Heavy Duty Heavy Duty Auger Drive Specs Our new X-treme auger drive has a new robust planetary gearbox capable of driving a 48” diameter auger. The X-treme auger drive you had known in the past is now our heavy duty auger drive and is still capable of driving up to a 36” diameter auger. The X-treme auger drive comes in a 2” hex drive while the heavy duty auger comes in a 2” hex or 2 9/16” round drive. *Heavy Duty Auger Drive pictured *side profile

• Direct drive through planetary gear
• Mounting plate, hoses and couplings included
• Various auger bit sizes and styles are available
• Heavy duty output shaft
• Heavy duty auger capable of driving up to 36" bit
• X-treme auger capable of driving up to 48" bit
• Excavator mounts available

Excavator Brush Cutter X-treme Excavator Brush Cutter Specs With our X-treme Excavator Brush Cutter, you will clear dense brush and trees up to 3" in diameter with the long lasting AR400 steel blades. Our X-treme Excavator Cutters are designed for Excavators with an operating weight of 12,000 lbs and over. The small size easily maneuvers in tight spaces at a job site, around buildings, fence lines or on your property. We have three different motor and gearbox combinations to achieve the highest torque available while maintaining a proven blade tip speed ideal for your operating machine. X-treme duty Standard Excavator Brush Cutter- 12-17 GPM & 17-24 GPM

Standard Duty Standard Excavator Brush Cutter Specs Our Standard Duty version is designed for mini excavators under 12,000 lbs. operating weight. It is offered in three different motor options that will allow you to clear dense brush and saplings up to 2" in diameter with long- lasting high tempered steel blades. Interchangable bolt on mounts available! X-Treme Excavator Brush Cutter – 14-20 & 20-26 & 24-30 GPM

• Cut tr ees up to 2"in diameter.
• Optional Star Motor (12-29 GPM)
• No Case Drain Required
• Cut tr ees up to 3" in diameter.
• Debris chains optional
• Optional Star Motor
