Resources: Official Product Page
D Series mini excavators from New Holland Construction are built in-house and are designed for an improved operator experience, performance and jobsite efficiency. The E12D is a more capable, versatile machine tailored for construction crews, landscapers, utility contractors and municipalities looking to do more with a compact framework.
| Model | E19D |
| Family | D Series Mini Excavators |
| Main Category | Mini Excavators |
| Gross HP | 18.4 HP (13.7 kW) |
| Operating Weight – Cab/Canopy | – / 4145 lbs (1880 kg) |
| Max Digging Depth – Std/Long Arm | 7 ft 6 in (2280) / 8 ft 2 in (2480 mm) |
| Max Dump Height- Std/Long Arm | 8 ft 6 in (2580 mm) / 8 ft 10 in (2700 mm) |
MINI EXCAVATOR, BIG POWER The E19D is powered by a 18.4 hp (13.7 kW) Stage V-certified Yanmar 3TNV76 engine, known for durability and low emissions. This power is housed in a compact and easily transportable package, measuring 7 ft 9 in (2370 mm) in height and 12 ft 8 in (3860 mm) in overall transport length. ARMED TO DIG ARMED TO DIG Specify your D Series compact excavator with the arm length to best suit your requi…
SIMPLE SERVICEABILITY For contractors and operators, serviceability is a key component to weigh when considering mini excavators. The E19D includes a tipping cab/canopy for full engine access, as well as three large side and rear panels that offer fast access to key service points. Just two bolts need to be removed to tip the cab.
